Low Voltage Power Bank Series - Built-in Energy Storage

Model

SMP-FU002

Battery Pack Parameters

Battery Pack Specifications

25.6V100Ah

Nominal Voltage

25.6V

Operating Voltage Range

21.6V ~ 28.8V

Rated Energy

2.56kWh

PV Input Parameters

Max. PV Open-Circuit Voltage

160VDC

MPPT Voltage Range

30~128VDC

Max. Input Power

1600W

Max. Charge/Discharge Current

50A

AC Output/Input Parameters

Input/Output Voltage

220~240VAC

Selectable Voltage Range

170V ~280VAC(UPS)/90V ~280VAC(APL)/184V ~253VAC(VDE)

Input Current

14A

Output Current

17A(terminal)/10A (socket)

Frequency

50Hz/60Hz(Adaptive)

Rated Output Power

3000W

General Parameters

Communication Protocol

RS485/WIFI

Operating Altitude

≤2000m

Cooling Method

Built-in Fan

Installation Method

Floor-standing

IP Rating

IP20

Cycle Life

≥6000 @ 25℃，80% DOD

Operating Temperature

0~55℃

Storage Temperature

-20~55℃

Humidity

≤80%

Product Dimensions

450*671*330mm

Packaging Dimensions

550*771*450mm

Product Net Weight

45kg
